CINEMA SUB
Subwoofer

Cinema SUB is the ultimate subwoofer for your home cinema installation. Designed to work with the Cinema LCR speaker, it delivers deep bass, enhancing every nuance of sound, even in the largest private cinema rooms up to 2153 sq ft (200m²). Advanced acoustic design, exclusive Focal technologies, customisation and modularity of the installation... With Cinema SUB, transform your movies into an unforgettable immersive experience.

THE CINEMA, AT HOME

Cinema SUB features two 13" woofers from the Sub12 subwoofer in our professional range. They ensure maximum excursion and uncompromising bass control for powerful, punchy bass. With its top-of-the-range design, it integrates perfectly into multichannel systems, sublimating every musical explosion and nuance for an intensely cinematic experience.

IMMERSION ON UTOPIA SCALE

Modular installation

The subwoofer can be mounted on or in the wall, or positioned horizontally or vertically. It can also be combined with other Cinema SUB and as many Cinema LCR as required, for a tailor-made installation. And it's discreetly integrated thanks to carefully designed fabric grilles.

COMPLETE SOLUTION

Utopia Cinema products - Cinema LCR and Cinema SUB - have been designed to create a complete and powerful home cinema installation. They can also be combined with the 1000 Series loudspeakers, which feature the same reference technologies such as the "W" cone of the speaker drivers, for total immersion with Utopia signature sound.

Specifications

Product type : Bass-Reflex Subwoofer
Membrane :
Sandwich "W"
Woofer : 2x13" 'W' cone woofers
Response at - 6dB (Low frequency point) : 2500 Hz
Frequency response (+/- 3dB) :
42hz- 2500Hz
Minimum impedance : 4.1 Ω
Nominal Impedance : 5 Ω
Recommended amplifier power : max 400W (8ohms) / max 800W (4ohms)
Sensitivity : 95 dB

Height : 1165 mm / 45.87 in
Width : 549 mm / 21.62 in
Depth : 326 mm / 12.8 in
Weight : 73 kg / 160.94 lb
Depth behind surface (Mounting depth) : 326 mm / 12.8 in

Cut Out template : Yes
Grilles : Fabric grille
